Display Panel
Removing the Display Panel
1. Follow the procedures in Before Working On Your Computer.
2. Remove the battery.
3. Remove the display bezel.
4. Remove the screws that secure that back panel.
5. Flip the display panel and disconnect the low-voltage differential signalling (LVDS) cable.
6. Remove the display panel from the display assembly.
