Setup and Specifications
Table Of Contents
- Dell Latitude 7400 2-in-1 Setup and specifications guide
- Set up your computer
- Create a USB recovery drive for Windows
- Chassis
- Keyboard shortcuts
- System specifications
- System information
- Processor
- Memory
- Base
- Intel vPro and Intel Standard Manageability
- Storage
- System board connectors
- Media card reader
- Audio
- Graphics Specifications
- Camera
- Communication Specifications
- External Ports and connectors
- Smart card reader
- Display specifications
- Keyboard
- Touchpad
- Operating system
- Battery
- Power adapter
- Physical system dimensions
- Computer environment
- NFC
- Fingerprint reader
- Security
- Regulatory and Environmental Compliance
- System setup
- Software
- Getting help
Feature Specications
• Noise reduction array microphones
Video HDMI 1.4
SIM card reader One micro SIM card reader (WWAN version only)
Smart card reader
Table 16. Contactless smart card reader
Type FIPS 201 Contacted / Contactless Smart Card reader
ISO certication ISO14443A
Display specications
Table 17. Display specications
Feature Specications
Type 14 inch FHD (1920 x 1080), AR + AS (16:9) WVA SLP narrow border
touch screen (10 nger and Active Stylus capable)
Height (Active area) 6.85 inch (173.99 mm)
Width (Active area) 12.18 inch (309.31 mm)
Diagonal 14 inch (354.89 mm)
Borders (AA to Glass)
• Top: 6.02 mm
• Bottom: 8.8 mm
• Sides: 3.73 mm
Luminance/Brightness (typical)
• 300 nits at 1.63 W (in mosaic pattern)
• 150 nits at 1.17 W
Refresh rate 60 Hz
Horizontal viewing angle (min) +/- 89 degrees
Vertical viewing angle (min) +/- 89 degrees
Megapixels 2.07
Pixels Per Inch (PPI) 157
Pixel pitch 0.161 mm
Color depth 16.2 M
Contrast ratio (typical) 1500:1
System specications 19
