Setup and Specifications

Video screen options
Table 31. Video
Option Description
LCD Brightness
Allows you to set the display brightness depending upon the power
source. On Battery(50% is default) and On AC (100 % default).
Dynamic Backlight Control
This option Enables or Disables the Dynamic Backlight Control if the
Panel supports this feature.
Security
Table 32. Security
Option Description
Admin Password
Allows you to set, change, or delete the administrator(admin) password.
The entries to set password are:
• Enter the old password:
• Enter the new password:
• Conrm new password:
Click OK once you set the password.
NOTE: For the rst time login, "Enter the old password:" eld is marked to "Not set". Hence,
password has to be set for the rst time you login and then you can change or delete the
password.
System Password
Allows you to set, change, or delete the System password.
The entries to set password are:
• Enter the old password:
• Enter the new password:
• Conrm new password:
Click OK once you set the password.
NOTE: For the rst time login, "Enter the old password:" eld is marked to "Not set". Hence,
password has to be set for the rst time you login and then you can change or delete the
password.
Strong Password
Allows you to enforce the option to always set strong password.
• Enable Strong Password
This option is not set by default.
Password Conguration
You can dene the length of your password. Min = 4, Max = 32
Password Bypass
Allows you to bypass the System password and the Internal HDD password, when it is set, during a system
restart.
30 System setup
