Related
Commands
• reload-type
— allows you to configure the reload-type options in reload-type sub
command mode.
• show reload-type — displays the current Reload mode (BMP mode or Normal
mode).
relay
Allows you to configure the addition of option 82 in DHCP client packets.
S4810, S4820T, S3048–ON, S4048–ON, S5000, S6000, S6000–ON, Z9100–
ON, Z9500, IOA, and MXL
Syntax
relay { enable | disable | remote-id { hostname | MAC | Word }}
To reset the options 82 information, use the no relay { enable | disable |
remote-id { hostname | MAC | Word }} command.
Parameters
enable
Enable the option 82 in BMP. The default value is the MAC
address.
disable
Disable the option 82 in BMP.
remote-id
{ hostname |
MAC | Word }
Enter the keyword remote-id, then the hostname or
chassis MAC address or a text string to set as the remote ID
in option 82. The default is the remote MAC ID for option
82.
Defaults none
Command Modes RELOAD-TYPE CONFIGURATION
Command History
This guide is platform-specific. For command information about other platforms,
see the relevant Dell Networking OS Command Line Reference Guide.
The following is a list of the Dell Networking OS version history for this command.
Version Description
9.8(1.0P1) Introduced on the Z9100–ON.
9.8(0.0P5) Introduced on the S4048–ON.
9.8(0.0P2) Introduced on the S3048–ON.
9.7(0.0) Introduced on the S4810, S4820T, S5000, S6000, S6000–
ON, Z9000, Z9500, IOA, and MXL.
Related
Commands
• reload-type — allows you to configure the reload-type options in reload-type
sub command mode.
Bare Metal Provisioning CLI
45
