To display the current reload mode for BMP, use the show bootvar or show
system brief commands. The show bootvar command includes the path of
the Dell Networking OS image file retrieved from a DHCP server when BMP is
running, but not after you exit BMP.
Example
Dell#show reload
reload-type : bmp [Next boot : bmp]
: enable
config-scr-download : enable
dhcp-timeout : 1
vendor-class-identifier : Device 609
retry-count : 3
Dell#
Related
Commands
reload-type — allows you to configure the reload-type options in reload-type sub
command mode.
stop bmp
To prevent an infinite loop, stop the switch from reloading in BMP mode.
S4810, S4820T, S3048–ON, S4048–ON, S5000, S6000, S6000–ON, Z9100–
ON, Z9500, and MXL
Syntax
stop bmp
NOTE: This command replaces the stop jumpstart command.
Defaults none
Command Modes EXEC
Command History
This guide is platform-specific. For command information about other platforms,
see the relevant Dell Networking OS Command Line Reference Guide.
The following is a list of the Dell Networking OS version history for this command.
Version Description
9.8(1.0P1) Introduced on the Z9100–ON.
9.8(0.0P5) Introduced on the S4048–ON.
9.8(0.0P2) Introduced on the S3048–ON.
9.7(0.0) Introduced on the S6000–ON.
9.6(0.0) Introduced on the S5000.
9.5(0.1) Introduced on the Z9500.
9.3(0.0) Introduced on the S6000. Replaces the stop jumpstart
command.
