• nfsmount://filepath copies from the nfs mount file system.
To remove an installed Open Automation package, such as Smart Scripting, use the package
uninstall
command.
To follow the progress of a package installation (or removal), use the show packages command.
Displaying Installed Packages
To view the Open Automation packages currently installed on a switch, including version numbers and
content, use the following command.
• View package information.
EXEC Privilege mode
show packages
show packages system
Uninstalling Smart Scripting
Uninstalling the Smart Scripting package removes it from the internal flash memory.
CAUTION: Before you uninstall the Smart Scripting package, stop all scripts that are running
using the no script script-name command. You must also manually stop the HTTP server
daemon.
• Uninstall the Smart Scripting package stored on the switch.
EXEC Privilege
package uninstall package-name
Enter the name of the Smart Scripting package exactly as it appears in the show packages list.
Dell Proprietary Utilities
Dell Networking OS provides the following utilities which are unique and helpful while scripting.
1. clido
2. dellsh
3. dellsyslog
clido
To configure any command on the device directly without handling it via the telenet or ssh sessions,
use the clido system command.
Syntax: clido “CLI command”
Example
clido "configure terminal"
clido "interface vlan 10"
clido "no shutdown"
