- Dell Networking Open Automation Guide December 2015
- About this Guide
- Open Automation Framework
- Bare Metal Provisioning
- Introduction
- How it Works
- Prerequisites
- Industrial Standard Upgrades with BMP
- BMP Process Overview
- BMP Operations
- Configure BMP
- BMP Commands and Examples
- System Boot and Set-Up Behavior in BMP Mode
- BMP Mode: Boot and Set-UP Behavior
- DHCP Offer Vendor-Specific Option for BMP
- DHCP Offer Relay Option 82
- Software Upgrade Using BMP
- Apply Configurations Using BMP Scripts
- Using the Post-Configuration Script
- Using Auto-Execution Script (Normal Mode Only)
- Timers in Pre–configuration and Post–configuration Scripts
- Script Examples
- BMP Operations on Servers Overview
- File Server Settings
- Domain Name Server Settings
- BMP MIB Support
- Bare Metal Provisioning CLI
- Open Management Infrastructure
- Puppet
- Smart Scripting
- Overview
- Download the Smart Scripting Package
- Dell Proprietary Utilities
- Dell SmartScript Utilities
- SQLite
- NET SNMP Client
- Limits on System Usage
- Supported UNIX Utilities
- Creating a User Name and Password for Smart Scripting
- Logging in to a NetBSD UNIX Shell
- Downloading Scripts to a Switch
- Setting a Search Path for Scripts
- Scheduling and Executing Scripts
- Running a Script from the UNIX Shell
- Running Scripts with User Privileges
- Smart Scripting CLI
- disable
- execute
- mount nfs
- package install
- package uninstall
- script (run)
- script (stop/resume/clear/kill/unschedule)
- script event-handler
- script execute (EXEC mode)
- script execute (CONFIGURATION mode)
- script get
- script path
- script remove
- script trigger-event
- show packages
- show script
- start shell
- triggered-by
- switch script limit
- username (event handler)
- username
- Virtual Server Networking
- Virtual Server Networking CLI
- REST API
- HTTP and HTTPS
- XML
- Important Points to Remember
- REST Authentication
- Request Query Parameters
- Sample BGP Configurations
- HTTP Status Error Codes
- REST API — Protocol Data Unit (PDU) Structure
- Configurations
- Operational
- Operational Data for IPv6
- Management Information Base (MIB)
- IETF Interface Operations
- REST API Framework to Execute the CLIs
- Samples of the config-command
- Samples of the EXEC command
- Samples of the show-command
- REST API CLI
- Web Server with HTTP Support

System Attributes Value Description
memory use
233,244 Maximum size (in bytes) to which
a process’s resident set size may
grow. This value imposes a limit
on the amount of physical
memory a process is given; if
memory is tight, the system
prefers to take memory from
processes that are exceeding
their declared resident set size.
memorylocked
77,741 Maximum size (in bytes) which a
process may lock into memory
using the mlock(2) function.
maxproc
160 Maximum number of
simultaneous processes allowed
for the user ID.
openfiles
64 Maximum number of open files
for this process.
Supported UNIX Utilities
Smart Scripting supports the invocation of the following UNIX utilities in the scripts you use.
UNIX Utility Function
arp
Address resolution display and control.
awk
Pattern scanning and processing language.
basename
Return filename or directory portion of pathname.
bc
An arbitrary precision calculator language.
cat
Concatenate and print files.
chmod
Change file modes.
chown
Change file owner and group.
cksum
Display file checksums and block counts.
cut
Select portions of each line of a file.
date
Display or set date and time.
dd
Convert and copy a file.
df
Display free disk space.
env
Set and print environment.
expr
Evaluate expression.
fc
List the history of commands on the computer.
fg
Change the background process to the foreground process.
Smart Scripting
81
