Version Description
9.5(0.1) Introduced on the Z9500.
9.2(0.0) Introduced on the MXL Switch.
9.0.2.0 Introduced on the S6000.
9.0.0.0 Introduced on the Z9000.
8.3.19.0 Introduced on the S4820T.
8.3.8.0 Introduced on the S4810.
Usage Information
In a stack setup, the Dell EMC Networking OS automatically synchronizes the software version installed on the
master stack unit with the other switches in the stack. To view the installed software versions on the stack units,
use the show packages system command.
NOTE: From Dell EMC Networking OS 9.10(0.0), the SmartScripts package supports the following script
versions:
• Perl — 5.14.2
• Python — 2.7.8
• Ruby — 1.9.3
Example (show
packages)
DellEMC#show packages
****************************************
Package Name:SMARTSCRIPTS Version:9.10(0.0)
Python 2.7.8
Perl 5.14.2
Data::Dumper 2.131
Class::MethodMaker 2.18
ExtUtils::MakeMaker 6.62
XML::NamespaceSupport 1.11
XML::SAX 0.96
XML::LibXML 1.96
Compress::Raw::Bzip2 2.049
Compress::Raw::Zlib 2.051
IO::Compress 2.049
URI 1.60
HTML::Tagset 3.20
HTML::Parser 3.69
LWP 5.836
Net::Telnet 3.03
OSSP::uuid 1.0602
UUID 0.02
version 0.97
Class::Inspector 1.27
Task::Weaken 1.04
Algorithm::Diff 1.1902
Text::Diff 1.41
SOAP::Lite 0.714
Crypt::SSLeay 0.58
URI::urn::uuid 0.03
UUID 0.03
Crypt::SSLeay 0.58
Net::SNMP 6.0.1
Net::Telnet::Cisco 1.10
DBI 1.623
Ruby 1.9.3-p545
libxml-ruby 2.3.0
mime-types 2.3
netrc 0.7.7
