Version Description
9.2(0.0) Introduced on the MXL switch.
8.3.19.0 Introduced on the S4820T.
8.3.8.0 Introduced on the S4810.
Usage Information
The show vmmap command displays information on the virtual machines accessed on a switch interface, including
the virtual machine name, VMAC address, and corresponding VLAN ID.
Example
DellEMC#show vmmap gigabitethernet 0/32
VM Name VIF Vlan ID
Redhat_207_03_nfs 00:0c:29:4f:66:19 -
Redhat_207_03_nfs 00:50:56:92:00:77 138
NOTE: In the show vmmap output, VLAN 1 displays as VLAN ID 1; VLAN 4095 displays without a
VLAN ID as "- ".
Related Commands hypervisor — denes a Hypervisor instance.
type
Sets the hypervisor type to VMware or Xen-Citrix.
S4810, S4820T, S5000, and MXL Switch
Syntax
[no] type {vmware | xen-citrix}
Parameters
vmware Set the hypervisor type as VMware.
xen-citrix Set the hypervisor type as Xen-Citrix.
Defaults none
Command Modes HYPERVISOR
Command History
This guide is platform-specic. For command information about other platforms, see the relevant Dell EMC
Networking OS Command Line Reference Guide.
The following is a list of the Dell EMC Networking OS version history for this command.
Version Description
9.6(0.0) Introduced on the S5000.
9.2(0.0) Introduced on the MXL switch.
8.3.19.0 Introduced on the S4820T.
8.3.8.0 Introduced on the S4810.
Usage Information
To enable VSN connections with virtual servers, congure a hypervisor type. To display the currently supported
hypervisor types, use the show hypervisor supported command.
138 Virtual Server Networking CLI
