Concept Guide

Request Query Parameters
Following are the various request query parameters supported on REST.
• deep — Retrieves a resource with all the subresources inline.
• shallow — Retrieves a resource with no subresources inline.
• select — Client uses to select the nodes and subresources.
• with-defaults — Client uses to control and display the default data in GET request.
To request a ltered partial response, use the select query parameter in the following patterns to specify the nodes and subresources.
• Use a semicolon separated list to select multiple nodes.
• Use a/b to select a node b that is nested within node a. Use a/b/c to select a node c nested within b.
• Use expressions in parentheses ( ) after any selected node to request specic subnodes.
• Use the wildcard notation within parentheses (*) to specify all sub nodes of a specic node.
NOTE: The node a/b/c;a/b/d is equivalent to a/b(c;d).
The following request selects the routes name and next-hop/name nodes:
GET
/running/sys/routes/inet/route/10.20.0.0,16?select=name;next-hop(name)
Sample BGP Congurations
The following are the sample BGP congurations via REST API.
Figure 3. BGP Topology
The PDU structure for conguring the IP address on an interface is as follows:
cat ipaddr_config_put.xml
<interface>
<name>tengig-0-0</name>
<ip>
<address>
<primary>
<address>11.1.1.1/24</address>
</primary>
</address>
</ip>
</interface>
The following conguration depicts the IP address conguration for router interfaces via REST– PUT request:
curl -v -u admin:admin http://10.16.151.159:8008/api/running/dell/interfaces/interface/
tengig-0-0 -X PUT -T ipaddr_config_put.xml
