+--ro interface [name]
+--ro name dell:interface-name
+--ro rule-entry [cam-index]
+--ro cam-index uint32
+--ro port? uint32
+--ro vlan-id? dell:vlan-id-num-with-default
+--ro protocol? dell:ip-protocols-type
+--ro tcp-flag* tcp-bits
+--ro source-port? uint32
+--ro destination-port? uint32
+--ro source-ip? string
+--ro destination-ip? string
+--ro nexthop-mac? string
+--ro egress-port? string
Port Mirroring
Use the following model to get the Port Mirroring operational data:
Module: STATS
URI:
/api/operational/dell/stats/monitor-session
Methods Supported: GET
Port Mirroring Operational Model
+--rw dell
+--rw stats
+--ro monitor-session [session-id source]
+--ro session-id uint32
+--ro source dell:interface-name
+--ro session-type? enumeration
+--ro destination? dell:interface-name
+--ro direction? enumeration
+--ro mode? enumeration
+--ro remote-vlan? dell:vlan-id-num
+--ro rspan-session-type? enumeration
+--ro source-ip? dell:ipv4-no-prefix
+--ro destination-ip? dell:ipv4-no-prefix
Access-List
The following denition describes how to retrieve all the Access-Lists (MAC and Layer 3):
Module:
STATIC ACCESS-LIST
URI:
/api/operational/dell/stats/access-list
Methods Supported: GET
Static Access-List Model
+--ro access-list
+--ro mac* [name]
| +--ro name access-list-name
| +--ro type? access-list-types
| +--ro mac-acl-filter* [seq-no]
