+--ro dynamic-in-active? uint32
+--ro static-active? uint32
+--ro static-inactive? uint32
+--ro route-size-active? uint32
+--ro route-size-in-active? uint32
Management Information Base (MIB)
Management Information Base (MIB) is a database of objects that can be monitored by a network management system. Dell EMC
Networking OS management information system (MIB) supports many new simple network management protocol (SNMP) objects and
notications. The following MIBS are translated and exposed via the REST API.
BGP V2
The following denition displays the properties of Interfaces using BGP V2:
Module: BGP – V2
URI:
/api/operational/mib/bgp-v2
Methods Supported: GET
BGP V2 Model
+--ro mib
+--ro bgp4-v2
+--ro dellNetBgpM2
| +--ro dellNetBgpM2CapabilitySupportAvailable? snmpv2-tc:TruthValue
| +--ro dellNetBgpM2AsSize? enumeration
| +--ro dellNetBgpM2LocalAs? inet-
address:InetAutonomousSystemNumber
| +--ro dellNetBgpM2LocalIdentifier? inet:ip-address
| +--ro dellNetBgpM2RouteReflector? snmpv2-tc:TruthValue
| +--ro dellNetBgpM2ClusterId? mib:dellNetBgpM2Identifier
| +--ro dellNetBgpM2ConfederationRouter? snmpv2-tc:TruthValue
| +--ro dellNetBgpM2ConfederationId? inet-
address:InetAutonomousSystemNumber
| +--ro dellNetBgpM2CfgBaseScalarStorageType? snmpv2-tc:StorageType
| +--ro dellNetBgpM2CfgLocalAs? inet-
address:InetAutonomousSystemNumber
| +--ro dellNetBgpM2CfgLocalIdentifier? inet:ip-address
| +--ro dellNetBgpM2CfgRouteReflector? snmpv2-tc:TruthValue
| +--ro dellNetBgpM2CfgClusterId? mib:dellNetBgpM2Identifier
| +--ro dellNetBgpM2CfgConfederationRouter? snmpv2-tc:TruthValue
| +--ro dellNetBgpM2CfgConfederationId? inet-
address:InetAutonomousSystemNumber
| +--ro dellNetBgpM2CfgPeerNextIndex? int32
| +--ro dellNetBgpM2PathAttrCount? yang:counter32
+--ro dellNetBgpM2VersionTable* [dellNetBgpM2VersionIndex]
| +--ro dellNetBgpM2VersionIndex uint32
| +--ro dellNetBgpM2VersionSupported? snmpv2-tc:TruthValue
+--ro dellNetBgpM2SupportedCapabilitiesTable* [dellNetBgpM2SupportedCapabilityCode]
| +--ro dellNetBgpM2SupportedCapabilityCode uint32
| +--ro dellNetBgpM2SupportedCapability? snmpv2-tc:TruthValue
+--ro dellNetBgpM2PeerTable* [dellNetBgpM2PeerInstance dellNetBgpM2PeerLocalAddr
dellNetBgpM2PeerRemoteAddr]
| +--ro dellNetBgpM2PeerInstance uint32
| +--ro dellNetBgpM2PeerIdentifier? inet:ip-address
| +--ro dellNetBgpM2PeerState? enumeration
| +--ro dellNetBgpM2PeerStatus? enumeration
| +--ro dellNetBgpM2PeerConfiguredVersion? uint32
| +--ro dellNetBgpM2PeerNegotiatedVersion? uint32
