Enumerating an Instance using a CIM Session
Create a CIM session
PS C:\Users\Administrator> $cred=Get-Credential -UserName:"omiuser" -Message:"OMI User?"
PS C:\Users\Administrator> $opt = New-CimSessionOption -UseSsl:$true -SkipCACheck:$true -
SkipCNCheck:$true -SkipRevocationCheck:$true
PS C:\Users\Administrator> $s6k=New-CimSession -Credential:$cred -ComputerName:10.10.60.1 -Port:
5986 -Authentication:basic -SessionOption:$opt
Get the CIM instance of various Resource View classes
PS C:\Users\Administrator> Get-CimInstance -ClassName MSFT_NetworkDevice_ConfigurationView -
Namespace root/Microsoft/
DesiredStateConfiguration -CimSession:$s6k
DeviceId : 90:b1:1c:f4:9d:23
HostName : S6000-1
Description :
Banner :
EnableBanner :
PSComputerName : 10.10.60.1
<snip...>
Classes and Schema Implementation
This section lists the implementation of classes and schema in OMI.
1 Prole Implementation
• CIM_RegisteredProfile
• CIM_ElementConformsToProfile
• CIM_PhysicalComputerSystemView
2 DesiredStateConguration (DSC)
• MSFT_NetworkDevice_AclView
• MSFT_NetworkDevice_BgpConfigurationView
• MSFT_NetworkDevice_BgpPeerView
• MSFT_NetworkDevice_ConfigurationView
• MSFT_NetworkDevice_EthernetPortView
• MSFT_NetworkDevice_MclagConfigurationView
• MSFT_NetworkDevice_PolicyMapView
• MSFT_NetworkDevice_PortChannelView
• MSFT_NetworkDevice_SnmpConfigurationView
• MSFT_NetworkDevice_StaticRouteView
• MSFT_NetworkDevice_VlanView
• MSFT_NetworkDevice_VrfContextView
3 Other Classes
• MSFT_NetworkDevice_CapabilityView (Only EI supported)
Open Management Infrastructure
