100 Working with Remote Access Controller
2
Click the number of the destination you want to configure.
NOTE: The number of destinations that you can configure on a given system
may vary.
3
Select the
Enable Destination
check-box.
4
Click
Destination Number
to enter an individual IP address for that
destination. This IP address is the IP address to which the platform event
alert is sent.
5
Enter a value in the
Community String
field to act as a password to
authenticate messages sent between a management station and a managed
system. The community string (also called the community name) is sent
in every packet between the management station and a managed system.
6
Click
Apply Changes
.
7
Click
Go Back to Platform Events Page
to go back to the
Platform Event
Filters
window.
