Table 6. PCIe SSD in Slot Card Properties (continued)
Properties Description
Device Protocol Displays the device protocol of the PCIe SSD in slot card,
such as Non-Volatile Memory Express (NVMe).
Media Displays the media type of the device.
Driver Version Displays the version of the driver that is installed on the PCIe
SSD subsystem.
NOTE: Storage Management displays Not Applicable
for subsystem for which the driver version cannot be
obtained.
Remaining Rated Write Endurance
Displays information on the SSD renewal/replacement based
on the amount of write workloads. This field indicates the
total remaining programs or erase-cycles available on the SSD,
based on the cumulative specification of the total NAND
(Negated AND or NOT AND) Flash chips in the SSD.
NOTE: This option is applicable to Micron PCIe SSDs,
Non-Volatile Memory Express (NVMe) PCIe SSDs, and
SAS/SATA SSDs.
Firmware Revision Displays the firmware version of the device.
NVMe Spec Version Displays the NVMe Spec version of the the PCIe SSD.
Model Number Displays the Piece Part Identification (PPID) of the PCIe SSD.
Capacity Displays the capacity of the device.
Vendor ID Displays the hardware vendor of the device.
Product ID Displays the product ID of the device.
Serial No. Displays the serial number of the device.
PCIe Negotiated Link Speed Displays the current negotiated transfer speed of the device
in GT/s.
PCIe Maximum Link Speed Displays the capable transfer speed of the device in GT/s.
PCIe Negotiated Link Width Displays the current negotiated link width of the device.
PCIe Maximum Link Width Displays the capable link width of the device.
Form Factor Displays the form factor of the device. Possible values are:
Add-in Card — For HHHL devices
2.5 inches — For physical devices other than a HHHL
device.
Sub Vendor Displays the vendor name of the device.
Available Spare Displays the available spare value set for all PCIe SSDs. The
new disk has 100% spare which will comes down as per the
usage.
PCIe SSD In Slot Card Tasks
You can perform the following tasks on the PCIe SSD in slot card:
To perform a PCIe SSD in slot card task:
1. In the Server Administrator window, under the System tree, expand the Storage tree object to display the storage
component objects.
2. Expand the PCIe SSD Subsystem object.
PCI Express Solid-State Device Support
39
