53-1001792-01 January 31, 2010 Fixed Rack Mount Kit Installation Procedure Supporting PowerConnect B-200E, 300, 4100, 4900, 5000, 5100, 5300, 7500 series, 7600, 7800, 8000, AP7420, Encryption Switch, and VA-40FC 53-1001792-01 *53-1001792-01*
Notes, Cautions, and Warnings NOTE A NOTE indicates important information that helps you make better use of your computer. CAUTION See the safety and regulatory information that shipped with your system. For additional regulatory information, see the Regulatory Compliance Homepage on www.dell.com at the following location: www.dell.com/regulatory_compliance. CAUTION A CAUTION indicates potential damage to hardware or loss of data if instructions are not followed.
In this guide • Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . • Installation requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . • Tool requirements and parts list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . • Installation procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
• Ensure that an electrical branch circuit with the following characteristics is available: - Required voltage and frequency as indicated in the hardware reference manual. (200-230 VAC is always preferred) - Protection by a circuit breaker in accordance with local electrical codes. Supply circuit, line fusing, and wire size that conform to the electrical rating on the switch nameplate. Grounded outlet compatible with the power cord and installed by a licensed electrician.
HT RIG 1 scale: 3/16" = 1" 2 B EV. 2 R 05 2-0 3/20 40 02 01/0 -00 N #2 CON X FO T LEF 3 4 5 6 (12x) (8-32 x 5/16 in.) 1 2 3 4 Bracket, front right Bracket, front left Bracket, rear left Bracket, rear right FIGURE 1 5 6 7 8 (8x) (6-32 x 1/4 in.) 7 (8x) (10-32 x 5/8 in.) 8 (8x) (10-32) Screw, 8-32 x 5/16 in., panhead Phillips Screw, 6-32 x 1/4 in., flathead Phillips Screw, 10-32 x 5/8 in.
Attaching front brackets Complete the following steps to attach the front brackets to the switch. 1. Position the right front bracket (Item 1) with the flat side against the right side of the switch (Figure 2). 2. Insert two 8-32 x 5/16 in. screws (Item 5) into one of the pairs of vertically aligned holes in the bracket and then into the pair of holes on the side of the switch. To install the switch in a recessed position in the cabinet, use the bracket holes that are set back from the end of the bracket.
2 T LEF scale: 1/8" = 1" H RIG T Silk Wor m ! 41 00 IO IO I LN K SP D V. B RE -02 2005 02 24 /03/ -000 N 01 #2 ON XC FO 1 8 7 1 2 Bracket, front right Bracket, front left 7 8 Screw, 10-32 x 5/8 in., panhead Phillips Retainer nut, 10-32 NOTE The figure above is shown with a recessed mounting configuration on the left and a flush mounting configuration on the right. You can select either mounting option.
6 RIG HT 4 B EV. 2 R 05 2-0 3/20 40 02 01/0 -00 N #2 CON X FO 1 4 Bracket, front right Bracket, rear right FIGURE 4 6 1 Screw, 6-32 x 1/4 in., flathead Phillips Position the rear and front brackets Attaching rear brackets to cabinet rails Complete the following steps to attach the rear brackets to the cabinet rails. 1. Attach the right rear bracket (Item 4) to the right rear cabinet rail using two 10-32 x 5/8 in. screws (Item 7) and two retainer nuts (Item 8) (Figure 5). 2.
7 RIG HT 4 8 B EV. 2 R 05 2-0 3/20 40 02 01/0 -00 N #2 CON X FO 1 4 Bracket, front right Bracket, rear right FIGURE 5 7 8 1 Screw, 10-32 x 5/8 in.
