Überwachung
Unter Verwendung von Lifecycle Controller können Sie den Hardwarebestand und die Ereignisse eines Servers während seines
Lebenszyklus überwachen.
Themen:
• Anzeigen und Exportieren der Hardware-Bestandsaufnahme
• About view and export current inventory
• Info-Ansicht und Exportieren der werksseitigen Bestandsliste
• Anzeigen der Hardwarebestandsliste (aktuelle oder werksseitige)
• Exportieren der Hardwarebestandsliste (aktuelle oder werksseitige)
• Anzeigen oder Exportieren der Hardwarebestandsliste nach der Teilersetzung
• Anzeigen oder Exportieren der aktuellen Bestandsliste nach dem Zurücksetzen von Lifecycle Controller
• Lifecycle Controller-Protokoll
Anzeigen und Exportieren der Hardware-
Bestandsaufnahme
Lifecycle Controller stellt die folgenden Assistenten zur Verwaltung der Systembestandsliste bereit:
● Anzeigen der derzeitigen Systembestandsliste
● Exportieren der derzeitigen Systembestandsliste
● Anzeigen der werkseitigen Bestandsliste
● Exportieren der werkseitigen Bestandsliste
● Systeminventar beim Neustart erfassen
About view and export current inventory
You can view information about the installed hardware components that are internal to the system chassis and the configuration for each
component. All the installed hardware components such as fans, PCI devices, NICs, DIMMs, PSU, and their properties and values are
displayed. You can export this information from a JSON file to a USB drive or network share. The JSON file is saved in the following
format: HardwareInventory_<servicetag>_<timestamp>.json.
For more information about the easy-to-use names of the hardware components, see Easy-To-Use System Component Names.
NOTE:
Incorrect inventory data is displayed or exported after performing a system erase. For viewing the correct inventory data, see
Viewing and Exporting Current Inventory After Resetting Lifecycle Controller.
NOTE: The inventory that is displayed in the Lifecycle Controller GUI may not be the same as that of any iDRAC interfaces. To get
the updated inventory, run the CSIOR, wait for 2 minutes, reboot the host, and then enter the LCUI.
NOTE: Some attributes like Primary status/Rollup status might show as Unknown while collecting inventory data from LCUI. This is
expected based on the availability of RTCEM inventory.
4
