Dell 10Gb Ethernet Pass Through -k for M1000e User Manual Rev 1.
Rev 1.0 ____________________ Information in this SXEOLFDWLRQ is subject to change without notice. © 2010 Dell Inc. All rights reserved. Reproduction of these materials in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden. Trademarks used in this text: Dell™, the DELL logo, and PowerEdge™ are trademarks of Dell Inc. Other trademarks and trade names may be used in this SXEOLFDWLRQ to refer to either the entities claiming the mark and names or their products. Dell Inc.
Dell -10GbE PTM Rev 1.0 Table of Contents Chapter 1 Chapter 2 5 Conventions 5 Overview 6 1.1 Features 6 1.2 Serial Number and Product Version Information 7 Installation and Basic Operation 8 2.1 Unpacking the Pass Through Module 8 2.2 Insertion and Removal of the PTM 8 2.2.1 PTM Insertion 8 2.2.2 PTM Removal 9 Connecting the External Ports 9 2.3.1 10 Gigabit Ethernet SFP+ Modules 9 2.3.2 Installation and Removal of Optical Transceiver Modules 9 2.3 2.
Rev 1.0 Related Documentation The documentation set accompanying the DEll Pass Through Module includes the following: Table 1 - Reference Documents and Web Sites Firmware and Firmware Update Tools support.dell.com Dell Pass Through Module Software User Manual support.dell.com Latest Supported Cables and Optical Modules Revision History Table 2 - Revision History 4 Revision Date Description 1.
Dell -10GbE PTM Rev 1.0 About this Manual This manual describes the installation and basic use of the Dell 10Gb Ethernet Pass Through -k 16 port module for blade servers. Intended Audience This manual is intended for users and system administrators responsible for installing and setting up the Dell 10Gb Ethernet Pass Through -k module for blade servers. Conventions The terms downlink (internal–from servers) and uplink (external–out to the world) are used throughout the document.
Rev 1.0 1 Overview Overview The PTM is an I/O module designed for the PowerEdge M1000e Dell Chassis. The product provides 10Gigabit connectivity for blade servers to Ethernet LANs. The product supports the following Ethernet protocols. Table 3 - Protocols Physical Connections Pass Through -k Protocol Blade Servers to PTM (Internal Links) KR Front Panel Ports (External Links) 10G XFI Each front panel port provides connectivity to the blade with the corresponding number in the chassis.
Dell -10GbE PTM Rev 1.0 Front Panel Indicators • Per port status LEDs: Link Up, Link Activity • System status LEDs: Power Supply, Status 1.2 Serial Number and Product Version Information The serial number and product version information are found on the label seen in the figure below.
Rev 1.0 Installation and Basic Operation 2 Installation and Basic Operation 2.1 Unpacking the Pass Through Module Before you install your new PTM, unpack it and make sure that there is no visible damage that may have occurred during shipping. Your package should contain the following items: • Dell 10Gb Ethernet Pass Through -k module for Blade Servers • This Users Manual The PTM is shipped without optical modules.
Dell -10GbE PTM Rev 1.0 The PTM supports hot-insertion into the chassis. If the PTM is inserted to a powered chassis, the power LED (green) should turn on immediately. 2.2.2 PTM Removal The PTM supports hot-removal. It may be removed when the chassis is powered on or off. The PTM must not be removed during a firmware update process. Note: Firmware update is in progress when the Yellow LED is blinking. 2.3 Connecting the External Ports The PTM front panel presents 16 SFP+ ports.
Rev 1.0 2.4 Installation and Basic Operation LED Indicators 2.4.1 System LEDs The system status LEDs indicate whether the PTM is receiving power from the chassis, and the state of the PTM. There are two system LEDs on the end of the module. The LED indications and meanings are explained in the figure and table below. Figure 5: Indicator LEDs The IO Module is on and ready when this LED is green. This LED can be blue or Yellow. A fault is indicated when the Yellow LED is blinking. See Table 4.
Dell -10GbE PTM Rev 1.0 network is discovered over the physical link. A valid data activity link without data transfer is designated by a constant yellow LED indication. A valid data activity link with data transfer is designated by a blinking yellow LED indication. If the LEDs are not active, either the physical link or the logical link (or both) connections have not been established.
Rev 1.0 Installation and Basic Operation 2.4.3 Installation Safety Warnings 1. Installation Instructions Read all installation instructions before connecting the equipment to the power source. 2. Over-temperature This equipment should not be operated in an area with an ambient temperature exceeding the maximum recommended: 40°C (104°F). An air flow of 9CFM at this maximum ambient temperature is required. 3.
Dell -10GbE PTM Rev 1.0 CLASS 1 LASER PRODUCT and reference to the most recent laser standards: IEC 60825-1:2007/03 y EN 60825-1:2007 2.4.4 Mechanical Installation 2.4.4.1 To install the PTM 1. Make sure that there is no foreign matter or dirt in the back plane connector or in the chassis slot. 2. Push the PTM into the chassis. Make sure that the ears on the latch hook onto the latching bar. 3. Push the latch handle towards the orange latch release until it locks. 2.4.4.2 To remove the PTM 1.
Rev 1.0 3 Troubleshooting Troubleshooting As soon as a pass through module is plugged in make sure that the status LED shows green. The power LED for the pass through module shuts off: 1. Check that the there is adequate ventilation. 2. Make sure that there is nothing blocking the front or rear of the chassis and that the fan modules and ventilation holes are not blocked (especially dust over the holes). 3.
Rev 1.0 Appendix A: Specifications Table 5 - Dell 10Gb Ethernet Pass Through Module Specification Data Physical Power and Environmental Size: W X D X H 24.7 cm X 28.5 cm X 2.9 cm Weight: 1.978kg SerDes Speeds: 10 Gb/s per port Connectors and Cabling: SFP+ Optical Cable: Direct attached copper cables supported Optical cables supported External Port Types: DAC (SFP+) Internal Port Types: KR Air Flow: 3CFM @ 30oC ambient temperature 9CFM @ 40oC ambient temperature 16 Maximum Power: 40.
Dell -10GbE PTM Rev 1.0 Table 5 - Dell 10Gb Ethernet Pass Through Module Specification Data Physical Power and Environmental Protocol Support Regulatory Compliance Ethernet: IEEE 802.3ae 10Gigabit Ethernet support Blade Servers to PTM (Internal Links): IEEE 802.3ap Ethernet Operation over Electrical Backplanes QoS: 8 Priority Queues for Ethernet Safety: UL60950 C-UL to CAN/CSA 22 2 No.
Rev 1.0 A.1: Mechanical Drawing with Dimensions All dimensions are in centimeters. Figure 7: Mechanical Drawing 24.7 23.0 5.5 2.
Dell -10GbE PTM Rev 1.0 Appendix B: Supported Cables and Media Types The following cables and optical modules are approved for the Dell PTM. Table 6 - Direct Attached Cables (DAC) DPN Reference Length (m) Speed Molex Custom PN K585N SFP-H10GB-CU1M 1 10.3125Gbps 74752-9093 J564N SFP-H10GB-CU3M 3 10.3125Gbps 74752-9094 H603N SFP-H10GB-CU5M 5 10.3125Gbps 74752-9096 G840N SFP-H10GB-CU7M 7 10.3125Gbps 74752-9098 R620M 30 AWG 0.5 10.3125Gbps 74752-1051 G692K 30 AWG 1 10.
Rev 1.0 Appendix C: EMC Certification Statements Table 8 lists the approved certification status per bridge in different regions of the world. Table 8 - Bridge Certification Status Pass through Module P/N FCC Class (USA) Dell 10GbE Pass Through -k A C.1: EN ICES Class Class (Europe) (Canada) A A VCCI (Japan) cTUVus KCC CB A FCC Statements (USA) Class A Statements: § 15.
Dell -10GbE PTM C.3: Rev 1.0 ICES Statements (Canada) Class A Statement: “This Class A digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada.” C.4: VCCI Statements (Japan) Class A Statement: C.4.1: Translation "This is a Class A product based on the standard of the Voluntary Control Council for Interference by Information Technology Equipment (VCCI).
Rev 1.0 C.5.1: Translation: “Class A Device This device is registered for EMC requirements for industrial use. The seller or buyer should be aware of this. If this type was sold or purchased by mistake, it should be replaced with a residential-use type.
Dell -10GbE PTM Rev 1.0 Appendix D: Interface Connector Pinouts D.1: SFP+ Interface VeeT 2 1 TX_Fault VeeT 20 TD3 TX_Disable 19 4 SDA 18 TD+ VeeT 5 SCL 17 6 MOD_ABS 16 7 RS0 15 VccT VccR VeeR RX_LOS 8 14 RD+ 13 9 RS1 12 10 VeeR 11 RD- VeeR Figure 8: SFP+ Connector Pinout - Rear View of Module With Pin Placement Table 9 - SFP+ Pinout Pin Symbol Name Description 1 VeeT Transmitter Ground (Common with Receiver Ground) a 2 TX_Fault Transmitter Fault.
Rev 1.0 Table 9 - SFP+ Pinout Pin Symbol Name Description 15 VccR Receiver Power Supply 16 VccT Transmitter Power Supply 17 VeeT Transmitter Ground (Common with Receiver Ground) a 18 TD+ Transmitter Non-Inverted DATA in. AC Coupled. 19 TD- Transmitter Inverted DATA in. AC Coupled. 20 VeeT Transmitter Ground (Common with Receiver Ground)a a. Circuit ground is internally isolated from chassis ground. b. TFAULT is an open collector/drain output, which should be pulled up with a 4.
