Dell -10GbE PTM Rev 1.0
17
Protocol Support Regulatory Compliance
Ethernet:
Blade Servers to
PTM (Internal
Links):
QoS:
IEEE 802.3ae 10Gigabit Ethernet
support
IEEE 802.3ap Ethernet Operation
over Electrical Backplanes
8 Priority Queues for Ethernet
Safety:
EMC
(Emissions):
Environmental:
UL60950
C-UL to CAN/CSA 22 2
No.60950-1
TUV/GS to EN 60950-1,
Amendment A1-A4, A11
CB-IEC60950-1, all coun-
try deviations
CC 47CFR Part 15 Class A
EN 55022 Class A
ICES-003 Class A
VCCI Class A
AS/NZS CISPR 22 Class A
CISPR 22 Class A
EN 55024
EN 300386
CE
EU: IEC 60068-2-64: Ran-
dom Vibration
EU: IEC 60068-2-29:
Shocks, Type I / II
EU: IEC 60068-2-32: Fall
Test
Table 5 - Dell 10Gb Ethernet Pass Through Module Specification Data
Physical Power and Environmental
