Dell -10GbE PTM Rev 1.0
19
Appendix B: Supported Cables and Media Types
The following cables and optical modules are approved for the Dell PTM.
Table 6 - Direct Attached Cables (DAC)
DPN Reference Length (m) Speed Molex Custom PN
K585N SFP-H10GB-CU1M 1 10.3125Gbps 74752-9093
J564N SFP-H10GB-CU3M 3 10.3125Gbps 74752-9094
H603N SFP-H10GB-CU5M 5 10.3125Gbps 74752-9096
G840N SFP-H10GB-CU7M 7 10.3125Gbps 74752-9098
R620M 30 AWG 0.5 10.3125Gbps 74752-1051
G692K 30 AWG 1 10.3125Gbps 74752-1101
P540M 30 AWG 2 10.3125Gbps 74752-1201
Y984J 28 AWG 3 10.3125Gbps 74752-2301
N651M 28 AWG 4 10.3125Gbps 74752-2401
C855K 28 AWG 5 10.3125Gbps 74752-3501
Table 7 - Optical Modules
DPN Reference Speed Manufacturer
N743D ASSY,XCVR,SFP+,LC-LC,SFP+SR 10.3125Gbps Finisar
T307D ASSY,XCVR,SFP+,LC-LC,SFP+LR 10.3125Gbps Finisar
W365M ASSY,XCVR,SFP+,LC-LC,SFP+SR,AV 10.3125Gbps Avago
W373M ASSY,XCVR,SFP+,LC-LC,SFP+LR,AV 10.3125Gbps Avago
