Error Code Message Information
Details Low voltages may be the result of a problem with the voltage regulator or a problem with
the processor. The low voltage may cause the processor to fail to operate.
Action
1. Turn system off and remove input power for one minute.
2. Reapply input power and turn system on.
3. Ensure the processor is seated correctly.
4. If the issue persists, see Getting Help.
CPU0201
Message CPU <
number
> <
name
> voltage is less than the lower critical threshold.
LCD Message CPU <
number
> <
name
> voltage is outside of range. Re-seat CPU.
Details Low voltages may be the result of a problem with the voltage regulator or a problem
with the processor. When the critical threshold is crossed, the processor will fail to
operate. The system may power down.
Action
1. Turn system off and remove input power for one minute.
2. Reapply input power and turn system on.
3. Ensure the processor is seated correctly.
4. If the issue persists, see Getting Help.
CPU0202
Message CPU <
number
> <
name
> voltage is greater than the upper warning threshold.
Details High voltages may be the result of problem with the voltage regulator or a problem with the
processor. Elevated voltages may result in damage to the processor or other electronic
components in side the system.
Action
1. Turn system off and remove input power for one minute.
2. Reapply input power and turn system on.
3. Ensure the processor is seated correctly.
4. If the issue persists, see Getting Help.
CPU0203
Message CPU <
number
> <
name
> voltage is greater than the upper critical threshold.
LCD Message CPU <
number
> <
name
> voltage is outside of range. Re-seat CPU.
Details High voltages may be the result of problem with the voltage regulator or a problem with
the processor. Elevated voltages may result in damage to the processor or other
system electrical components. The system may power down.
Action
1. Turn system off and remove input power for one minute.
2. Reapply input power and turn system on.
3. Ensure the processor is seated correctly.
4. If the issue persists, see Getting Help.
CPU0204
Message CPU <
number
> <
name
> voltage is outside of range.
