Drives
0 through 23 and two optional 2.5 inch back-accessible SAS,
Nearline SAS, or SSD hard drives in hard-drive slots 24 and
25.
Optical drive
(PowerEdge R720)
One optional SATA DVD-ROM drive or DVD+/-RW drive.
NOTE
: DVD devices are data only.
Connectors
Back
NIC Four 10/100/1000 Mbps or two 10/100/1000 Mbps and two
100 Mbps/1 Gbps/10 Gbps
Serial 9-pin, DTE, 16550-compatible
USB Two 4-pin, USB 2.0-compliant
Video 15-pin VGA
External vFlash card
(PowerEdge R720xd)
One flash memory card slot with iDRAC7 Enterprise card
NOTE
: The card slot is available for use only if the
iDRAC7 Enterprise license is installed on your
system.
Front
USB Two 4-pin, USB 2.0-compliant (PowerEdge R720)
One 4-pin, USB 2.0-compliant (PowerEdge R720xd)
Video 15-pin VGA
External vFlash card
(PowerEdge R720)
One flash memory card slot with iDRAC7 Enterprise card
NOTE
: The card slot is available for use only if the
iDRAC7 Enterprise license is installed on your
system.
Internal
USB One 4-pin, USB 2.0-compliant
Internal Dual SD Module Two optional flash memory card slots with the internal SD
module
NOTE
: One card slot is dedicated for redundancy.
Video
Video type Integrated Matrox G200
Video memory 16 MB shared
