Dell™ PowerEdge™ 4210 Installation Guide 19
8
Reverse the badge on the front door.
a
Open the front door.
b
Remove the two retention screws on the badge with a #2 Phillips
screwdriver.
c
Remove the badge.
d
Turn the badge 180 degrees so that it will read correctly when
reinstalled.
e
Place the badge on the front of the door and align the badge with the
marks on the inside of the door.
f
Using the screws removed in step b, install the badge.
Securing the Rack Leveling Feet
CAUTION: Read all statements below before you adjust the leveling feet.
Your rack includes four leveling feet, which are mounted on the corners of the
rack. The leveling feet are designed to align the rack in an upright, level
position when the rack is situated on a slightly uneven floor surface. Before
you install your systems in the rack, deploy and adjust the leveling feet. When
you level your rack, follow these guidelines.
CAUTION: When you adjust the leveling feet, ensure that the casters on each
corner of the rack do not rise more than 9.5 mm (3/8 inch) above the floor. If you
exceed 9.5 mm of clearance between the floor and the casters as you adjust the
leveling feet, slowly retract the leveling feet, and then move the rack to another
location that requires minimal adjustments to the leveling feet.
CAUTION: Adjust the leveling feet until each leveling foot rests firmly on the
floor. Proper contact with the floor ensures that each leveling foot is supporting
the weight of the rack and prevents the rack from swaying in any direction. If the
leveling feet are not all in firm contact with the floor, the rack can become
unstable and tip over.
CAUTION: Do not attempt to move your rack with the leveling feet deployed.
Always retract the leveling feet before moving the rack. Having the leveling feet
deployed when you move the rack may cause the rack to tip over.
CAUTION: Always level the rack and install the stabilizing feet before you install
your systems. A fully loaded rack may tip over if your rack is resting on an uneven
floor surface and the leveling and stabilizing feet are not supporting the weight of
the rack.
