Adjusting the Rack Posts (Optional)
The position of the rack posts can be adjusted to accommodate systems
of various depths.
1
Open the rack doors.
2 Remove the screws on the bottom, middle, and top of the post
(see Figure 1-15).
3 Move the post to the desired location inside the side of the rack,
and replace the screws in the corresponding holes.
Figure 1-15. Adjusting the Rack Posts
NOTE: Unless you need to couple two or more racks, you may now install systems
into the rack. Refer to the white numbered labels on the front and back of the rack
mounting rails for information on installing components in the rack.
1 screws 2 back rack post
3 front rack post
1
2
3
