Table 5. SFS personalities in VxRail deployment
L2 Single Rack personality L3 multi rack personality
Enabled SFS by running a Python script in the OS10 Linux
shell.
Enable SFS using CLI, API, or UI.
Existing deployments when upgraded to SmartFabric
OS10.5.0.5 continue to run in the L2 fabric profile and L3
fabric capabilities are not available. If you upgrade switches
with L2 personality to OS10.5.0.5, SFS operates with the
VxRail L2 single rack personality.
Dell Technologies recommends that you enable all new
deployments with L3 leaf and spine fabric personality. You
cannot upgrade VxRail with SFS deployments to the new L3
leaf and spine fabric personality automatically.
Support matrix
See Networking Solutions Support Matrix regarding support matrices for SFS with VxRail across various releases.
Fabric operations and life cycle management
Dell EMC OpenManage Network Integration (OMNI) enables you to configure and manage SFS-enabled PowerSwitches in
different deployments. You can use OMNI application to manage and operate one or more SFS instances either directly using
the OMNI UI through a web browser or through a vCenter plug-in. After initial deployments, Dell Technologies recommends that
you use OMNI UI to perform all fabric management and life cycle management activities.
For more information about OMNI, see OMNI Documentation.
