9GB1XC3 fde1:53ba:e9a0:de14:e6f0:4ff:fe3e:45dd ONLINE
MASTER MX9116n SKY002L B1
Example (VxRail)
OS10# show smartfabric cluster member
Service-tag IP Address Status
Role Type Chassis-Service-Tag Chassis-Slot
-----------------------------------------------------------
3Z4ZZP2 fde2:53ba:e9a0:cccc:54bf:64ff:fee6:e462 ONLINE
BACKUP
3Z4ZZP1 fde2:53ba:e9a0:cccc:54bf:64ff:fee6:e463 ONLINE
BACKUP
BR2ZZP2 fde2:53ba:e9a0:cccc:3c2c:30ff:fe49:2585 ONLINE
BACKUP
B37HXC2 fde2:53ba:e9a0:cccc:e4f0:4ff:feb6:fdc3 ONLINE
MASTER
G17HXC2 fde2:53ba:e9a0:cccc:e4f0:4ff:feb6:e1c3 ONLINE
BACKUP
Supported
Releases
● MX9116n and MX5108n—10.5.0.1 or later
● SFS-supported OS10 switches—10.5.0.3 or later
show smartfabric configured-server
Displays list of all configured servers information in a fabric. Information includes ID, model type, slot, chassis model and service
tag, bonding technology, list of existing bond members, and server status.
Syntax
show smartfabric configured-server
Parameters None
Default None
Command Mode EXEC
Usage
Information
This command is supported in both Full Switch and SFS modes.
Example (IOM)
MX9116N-B1# show smartfabric configured-server
----------------------------------------------------------
Service-Tag : 00FWX20
Server-Model : PowerEdge MX740c
Chassis-Slot : 1
Chassis-Model : POWEREDGE MX7000
Chassis-Service-Tag : SKY002L
Is-Discovered : TRUE
Is-Onboarded : TRUE
Is-Configured : TRUE
**********************************************************
Bonding Technology : LACP
BondMembers:
Nic-Id : Switch-Interface
----------------------------------------------------------
NIC.Mezzanine.1A-1-1 3GB1XC2:ethernet1/1/1
NIC.Mezzanine.1A-2-1 9A2HEM3:port-channel1
----------------------------------------------------------
Supported
Releases
10.5.1.0 or later
46 SFS commands
