show smartfabric details
Displays all details specific to the fabric. Details include name, description, ID, nodes that are part of the fabric, design type
associated with the fabric, and status detail of a fabric.
Syntax
show smartfabric details
Parameters None
Default None
Command Mode EXEC
Usage
Information
This command is supported in both Full Switch and SFS modes.
Example (IOM)
MX9116N-A1# show smartfabric details
----------------------------------------------------------
Name : A1-A2
Description :
ID : fc6c9051-f499-4816-a54a-25ef6fef2e33
DesignType : 2xMX9116n_Fabric_Switching_Engines_in_same_chassis
Validation Status: VALID
VLTi Status : VALID
Placement Status : VALID
Nodes : 3GB1XC2, 9A2HEM3
----------------------------------------------------------
Example (VxRail)
OS10# show smartfabric details
----------------------------------------------------------
Name : AutoFab-08ee685b-d6d6-5d0c-99d2-ae78f800d4b7
Description : Auto-Fabric Generator
ID : 08ee685b-d6d6-5d0c-99d2-ae78f800d4b7
DesignType : AutoFabricDesign--1
Validation Status: VALID
VLTi Status : VALID
Placement Status : VALID
Nodes : CAC00N2, AZY1234
----------------------------------------------------------
----------------------------------------------------------
Name : AutoFab-100
Description : Auto-Fabric Generator
ID : 100
DesignType :
Validation Status: VALID
VLTi Status : VALID
Placement Status : VALID
Nodes : AZY1234, CAC00N2, 9GTWNK2, FHTWNK2
----------------------------------------------------------
Supported
Releases
● MX9116n and MX5108n—10.5.0.1 or later
● SFS-supported OS10 switches—10.5.0.3 or later
show smartfabric discovered-server
Displays information about all the discovered servers. Information includes server tag, model, slot, chassis model, and chassis
service tag.
Syntax
show smartfabric discovered-server
Parameters None
Default None
Command Mode EXEC
