Users Guide

Supported
Releases
10.5.1.0 or later
ptp priority2
Configures the priority2 attribute for advertising PTP clock.
Syntax
ptp priority2 priority-number
Parameters priority-number—Priority2 has the fifth precedence among the six attributes that are used in the
selection of the master clock. Enter a value from 0 to 255.
Defaults 128
Command Mode CONFIGURATION
Security and
Access
Netadmin and sysadmin
Usage
Information
The lower the value of this attribute, the higher is the priority. The no form of this command removes the
configuration.
Example
OS10(config)# ptp priority2 120
Supported
Releases
10.5.1.0 or later
ptp role
Configures the interface to operate in master, slave, or dynamic role.
Syntax
ptp role {dynamic | master | slave}
Parameters
● master—Enables master role only on the interface
● slave—Enables slave role only on the interface
● dynamic—Enables dynamic role on the interface. The interface can be a master or slave based on
the best master clock algorithm (BMCA).
Defaults Dynamic
Command Mode INTERFACE CONFIGURATION
Security and
Access
Netadmin and sysadmin
Usage
Information
If the configuration conflicts with unicast transport mode, this command returns an error. The no form of
this command removes the configuration.
Example
OS10(config)# interface ethernet 1/1/1
OS10(conf-if-eth1/1/1)# ptp role master
Supported
Releases
10.5.1.0 or later
ptp source
Configures the source IP address for the PTP multicast packets.
Syntax
ptp source {ipv4 ipv4-address | ipv6 ipv6-address}
Parameters
● ipv4-address—Source IPv4 address for the PTP multicast packets
● ipv6-address—Source IPv6 address for the PTP multicast packets
System management 191
