Reference Guide

Parameters
queue-id Enter the value used to identify a queue. The range is from 0
to 7.
class-map
class-map-
name
(OPTIONAL) Enter the keyword class-map then the class
map name assigned to the queue in character format (16
character maximum).
NOTE: This option is available under policy-map-
input
only.
qos-policy
qos-policy-
name
(OPTIONAL) Enter the keywords qos-policy then the QoS
policy name assigned to the queue in text format (16
characters maximum). This specifies the input QoS policy
assigned to the queue under
policy-map-input and
output QoS policy under policy-map-output context.
Defaults none
Command
Modes
CONFIGURATION (conf-policy-map-in and conf-policy-map-out)
Command
History
This guide is platform-specific. For command information about other platforms,
refer to the relevant Dell Networking OS Command Line Reference Guide.
The following is a list of the Dell Networking OS version history for this command.
Version 9.0.2.0 Introduced on the S6000.
Version
8.3.19.0
Introduced on the S4820T.
Version 8.3.11.1 Introduced on the Z9000.
Version 8.3.7.0 Introduced on the S4810.
Version 7.6.1.0 Introduced on the S-Series.
Version 7.5.1.0 Introduced on the C-Series.
pre-Version
6.1.1.1
Introduced on the E-Series.
Usage
Information
There are eight queues per interface on the S6000 and four queues on the S-
Series. This command assigns a class map or QoS policy to different queues.
Related
Commands
class-map — identifies the class map.
service-policy input — applies an input policy map to the selected interface.
service-policy output — applies an output policy map to the selected interface.
Quality of Service (QoS)
