Specications
This section lists the S5148F-ON switch specications.
CAUTION: Operate the product at an ambient temperature not higher than 45°C (113°F).
CAUTION: Lithium Battery Caution: There is a danger of explosion if the battery is incorrectly replaced. Replace only with same
or equivalent type of battery. Dispose of the batteries according to the manufacturer's instructions.
NOTE: For RoHS information, see Restricted Material Compliance.
Topics:
• Chassis physical design
• IEEE standards
• Agency compliance
• USA Federal Communications Commission statement
• European Union EMC directive conformance statement
• Japan VCCI compliance for class A equipment
• Korean certication of compliance
• Safety standards and compliance agency certications
• Electromagnetic compatibility
• Product recycling and disposal
Chassis physical design
Table 5. Chassis physical design
Parameter Specications
Height 1.72 inches (44 mm)
Width 17.1 inches (434 mm)
Depth
Chassis: 18.2 inches (462 mm)
PSU/fan tray handle: 1.57 inches (40 mm)
Chassis weight with factory-installed components
19 lbs (2* PSUs)
8.62 kg (2*PSUs)
Rack clearance required
Front: 5 inches (12.7 cm)
Back: 5 inches (12.7 cm)
