Setup Guide
Table Of Contents
- Dell PowerVault 56F Switches Rack Installation Guide
- Safety Instructions
- Contents
- Dell™ PowerVault™ 56F 16-Port Fibre Channel Switch Rack Installation Guide
- Rack Components
- Before You Begin
- Installing the Rack Kit
- 1. Remove the rack’s front and back doors.
- 2. Install the slide assemblies in the rack.
- Removing the Doors From a 24-U or 42-U Rack
- 1. Open the latch on the front door.
- Figure 2. Opening the 24-U Rack Cabinet Front Door Latch
- Figure 3. Opening the 42-U Rack Cabinet Front Door Latch
- Figure 4. Removing the 24-U Rack Cabinet Doors
- a. One person should grasp the top of the door to stabilize it. The other person should grasp the...
- b. The person holding the bottom of the door should press the release lever on the bottom hinge a...
- c. The person holding the top of the door should press the release lever on the top hinge and the...
- Figure 5. Removing the 42-U Rack Cabinet Doors
- Installing the Slide Assemblies in the Rack
- Installing the Switch in the Rack
- 1. Lift the switch and align its slide rails to fit inside the slide assemblies on the rack (see ...
- 2. Slide the switch into the rack until both latch assemblies snap into place.
- 3. Lift the manifold (the component that attaches to the front of the switch and align its rails ...
- Figure 9. Installing the Manifold
- Replacing the Doors
- 1. Lift the front door into position and align the hinges with the hinge insert in the rack as sh...
- 2. Slide the hinge pins into the hinge insert in the rack until the hinges lock into position.
- 3. Verify that the hinges are latched.
- 4. Close the door latch by rotating the handle counterclockwise until it stops (see Figure 2).
- 5. Repeat steps 1 through 4 to replace the back door.
- 1. Lift the front door into position and align the hinges with the holes in the rack as shown in ...
- 2. Slide the hinges into the holes in the rack until the hinge release levers lock the hinges int...
- 3. Verify that the hinges are latched.
- 4. Close the door latch by rotating the handle counterclockwise until it stops, push in the handl...
- 5. Repeat steps 1 through 4 to replace the back door.
- Index
xi
3. Disconnect
your computer and devices from their power sources. Also, discon-
nect any telephone or telecommunication lines from the computer.
Doing so reduces the potential for personal injury or shock.
In addition, take note of these safety guidelines when appropriate:
When you disconnect a cable, pull on its connector or on its strain-relief loop, not
on the cable itself. Some cables have a connector with locking tabs; if you are dis-
connecting this type of cable, press in on the locking tabs before disconnecting
the cable. As you pull connectors apart, keep them evenly aligned to avoid bend-
ing any connector pins. Also, before you connect a cable, make sure that both
connectors are correctly oriented and aligned.
Handle components and cards with care. Don’t touch the components or con-
tacts on a card. Hold a card by its edges or by its metal mounting bracket. Hold a
component such as a microprocessor chip by its edges, not by its pins.
'
%()
*
+
Static electricity can harm delicate components inside your computer. To prevent
static damage, discharge static electricity from your body before you touch any of
your computer’s electronic components, such as the microprocessor. You can do so
by touching an unpainted metal surface on the computer chassis.
As you continue to work inside the computer, periodically touch an unpainted metal
surface to remove any static charge your body may have accumulated.
You can also take the following steps to prevent damage from electrostatic discharge
(ESD):
When unpacking a static-sensitive component from its shipping carton, do not
remove the component from the antistatic packing material until you are ready to
install the component in your computer. Just before unwrapping the antistatic
packaging, be sure to discharge static electricity from your body.
When transporting a sensitive component, first place it in an antistatic container
or packaging.
Handle all sensitive components in a static-safe area. If possible, use antistatic
floor pads and workbench pads.
The following notice may appear throughout this document to remind you of these
precautions:
.9:*;
886nceb0.book Page xi Friday, April 14, 2000 9:37 AM
