- Dell PowerVault 56F Switches Rack Installation Guide
- Safety Instructions
- Contents
- Dell™ PowerVault™ 56F 16-Port Fibre Channel Switch Rack Installation Guide
- Rack Components
- Before You Begin
- Installing the Rack Kit
- 1. Remove the rack’s front and back doors.
- 2. Install the slide assemblies in the rack.
- Removing the Doors From a 24-U or 42-U Rack
- 1. Open the latch on the front door.
- Figure 2. Opening the 24-U Rack Cabinet Front Door Latch
- Figure 3. Opening the 42-U Rack Cabinet Front Door Latch
- Figure 4. Removing the 24-U Rack Cabinet Doors
- a. One person should grasp the top of the door to stabilize it. The other person should grasp the...
- b. The person holding the bottom of the door should press the release lever on the bottom hinge a...
- c. The person holding the top of the door should press the release lever on the top hinge and the...
- Figure 5. Removing the 42-U Rack Cabinet Doors
- Installing the Slide Assemblies in the Rack
- Installing the Switch in the Rack
- 1. Lift the switch and align its slide rails to fit inside the slide assemblies on the rack (see ...
- 2. Slide the switch into the rack until both latch assemblies snap into place.
- 3. Lift the manifold (the component that attaches to the front of the switch and align its rails ...
- Figure 9. Installing the Manifold
- Replacing the Doors
- 1. Lift the front door into position and align the hinges with the hinge insert in the rack as sh...
- 2. Slide the hinge pins into the hinge insert in the rack until the hinges lock into position.
- 3. Verify that the hinges are latched.
- 4. Close the door latch by rotating the handle counterclockwise until it stops (see Figure 2).
- 5. Repeat steps 1 through 4 to replace the back door.
- 1. Lift the front door into position and align the hinges with the holes in the rack as shown in ...
- 2. Slide the hinges into the holes in the rack until the hinge release levers lock the hinges int...
- 3. Verify that the hinges are latched.
- 4. Close the door latch by rotating the handle counterclockwise until it stops, push in the handl...
- 5. Repeat steps 1 through 4 to replace the back door.
