22 About Your System
E1310 RPM Fan ## RPM of specified cooling
fan is out of acceptable
operating range.
See "Troubleshooting
System Cooling Problems"
on page 140.
E1313 Fan
Redundancy
The system is no longer
fan-redundant. Another
fan failure will put the
system at risk of over-
heating.
Check control panel LCD
for additional scrolling
messages. See
"Troubleshooting System
Cooling Problems" on
page 140.
E1410 CPU # IERR Specified microprocessor
is reporting an internal
error.
See your system’s
Information Update Tech
Sheet located on
support.dell.com for the
most current system
information. If problem
persists, see "Getting Help"
on page 167.
Table 1-6. LCD Status Messages (continued)
Code Text Causes Corrective Actions
