Inside the System
CAUTION: Many repairs may only be done by a certified service technician. You
should only perform troubleshooting and simple repairs as authorized in your
product documentation, or as directed by the online or telephone service and
support team. Damage due to servicing that is not authorized by Dell is not covered
by your warranty. Read and follow the safety instructions that came with the
product.
In Figure 3-1, the bezel and system cover are removed to provide an interior
view of the system.
Figure 3-1. Inside the System
5
3
2
11
12
13
4
8
9
1
7
6
10
