270 Troubleshooting: Your Storage Array Software
Recovery Guru
The Recovery Guru is a component of MDSM that diagnoses critical events
on the storage array and recommends step-by-step recovery procedures for
problem resolution.
In the AMW, to display the Recovery Guru, perform one of these actions:
•Click
Recovery Guru
.
•In the
Support
tab, click the
Recover from Failure
link.
•From the
Status
pane on the
Summary
tab, click the
Storage Array Needs
Attention
link.
You can detect a problem using the following indicators:
• Non-Optimal status icons
• Alert notification messages that are sent to the appropriate destinations
• Hardware indicator lights
The status icons return to Optimal status as problems are resolved.
Storage Array Profile
The storage array profile provides a description of all of the components and
properties of the storage array. The storage array profile also provides the
option to save the storage array profile information to a text file. You might
want to use the storage array profile as an aid during recovery or as an
overview of the current configuration of the storage array. Create a new copy
of the storage array profile if your configuration changes.
To open the storage array profile:
1
In the AMW, perform one of the following actions:
• Select
Storage Array
View
Profile
.
• Select the
Summary
tab, and click
Storage Array Profile
in the
Status
area.
• Select the
Support
tab, and click
View Storage Array Profile
.
The
Storage Array Profile
dialog appears. The Storage Array Profile dialog
contains several tabs, and the title of each tab corresponds to the subject
of the information contained.
