Configuration: Premium Feature—Snapshot Virtual Disks 149

• Percent Full—When the snapshot repository virtual disk reaches the user-

specified repository full percentage level, the event is logged in the Major

Event Log (MEL). The default snapshot repository full percentage level is

50% of the source virtual disk.

• Snapshot Repository Virtual Disk Full Conditions—Choose whether to

fail writes to the source virtual disk or fail the snapshot virtual disk when

the snapshot repository virtual disk becomes full.

• Host-to-Virtual Disk Mapping—Choose whether to map the snapshot

virtual disk to a host or host group now or to map the snapshot virtual disk

later. The default setting is Map later.

Preparing Host Servers to Create the Snapshot Using the Advanced Path

NOTE: Before using the Snapshot Virtual Disks Premium Feature in a Microsoft

Windows clustered configuration, you must first map the snapshot virtual disk to

the cluster node that owns the source virtual disk. This ensures that the cluster

nodes correctly recognize the snapshot virtual disk.

NOTE: Mapping the snapshot virtual disk to the node that does not own the source

virtual disk before the Snapshot enabling process is completed can result in the

operating system mis-identifying the snapshot virtual disk. This, in turn, can result in

data loss on the source virtual disk or an inaccessible snapshot.

NOTE: For details on mapping the snapshot virtual disk to the secondary node, see

the

Dell PowerVault MD3200 and MD3220 Storage Arrays With Microsoft Windows

Server Failover Clusters

on support.dell.com/manuals.

The destination of a snapshot repository virtual disk is determined based on

the free capacity available in the disk group. A snapshot repository virtual disk

requires a minimum 8 MB of free capacity. You can choose your preferred

creation path—simple or advanced—if the disk group of the source virtual

disk has the required amount of free space.

If 8 MB of free capacity is not available in the disk group of the source virtual

disk, the Create Snapshot Virtual Disks feature defaults to the advanced

path see "Creating a Snapshot Virtual Disk Using the Advanced Path" on

page 148. In the advanced path option, you can choose to place the snapshot

repository virtual disk in another disk group or you can use unconfigured

capacity on the storage array to create a new disk group.

NOTE: You can create concurrent snapshots of a source virtual disk on both the

source disk group and on another disk group.

book.book Page 149 Wednesday, June 8, 2011 5:01 PM
