40 Planning: MD3600f Series Storage Array Terms and Concepts
Physical Disks
Only Dell supported 6.0 Gbps SAS physical disks are supported in the storage
array. If the storage array detects unsupported physical disks, it marks the disk
as unsupported and the physical disk becomes unavailable for all operations.
NOTE: The MD3600f Series array must contain at least two physical disks for
proper operation. This is necessary because the physical disks are used to store
configuration information.
Physical Disk States
The storage array recognizes the physical disk states. Mode and status of
physical disks are reported in the MDSM application. Possible values for
mode and status are described in Table 4-1.
Table 4-1. RAID Controller Physical Disk States
Status Mode Description Physical Disk
Status LED
Optimal Assigned The physical disk in the indicated slot
is configured as part of a disk group.
Steady Green
Optimal Unassigned The physical disk in the indicated slot
is unused and available to be
configured.
Steady Green
Optimal Hot Spare
standby
The physical disk in the indicated slot
is configured as a hot spare.
Steady Green
Optimal Hot Spare in
use
The physical disk in the indicated slot is
in use as a hot spare within a disk group.
Steady Green
Failed Assigned,
Unassigned,
Hot Spare in
use, or Hot
Spare standby
The physical disk in the indicated slot
has failed because of an unrecoverable
error, an incorrect drive type or drive
size, or by its operational state being
set to failed.
Amber flashing
(150 ms)
Replaced Assigned The physical disk in the indicated slot
has been replaced and is ready to be,
or is actively being, configured into a
disk group.
Green flashing
(On 400 ms, Off
100 ms)
