42 Planning: MD3600f Series Storage Array Terms and Concepts

Disk groups are always created in the unconfigured capacity of a storage array.

Unconfigured capacity is the available physical disk space not already

assigned in the storage array.

Virtual disks are created within the free capacity of a disk group. Free capacity

is the space in a disk group that has not been assigned to a virtual disk.

Virtual Disk States

The storage array recognizes the following virtual disk states.

Table 4-2. RAID Controller Virtual Disk States

State Description

Optimal The virtual disk contains physical disks that are all online.

Degraded The virtual disk with a redundant RAID level contains an inaccessible

physical disk. The system can still work properly, but performance may

be affected and additional disk failures may result in data loss.

Offline A virtual disk with one or more member disks in an inaccessible (failed,

missing, or offline) state. Data on the virtual disk is no longer accessible.

Force online The storage array forces a virtual disk that is in an Offline state to an

Optimal state. If all the member physical disks are not available, the

storage array forces the virtual disk to a Degraded state. The storage

array can force a virtual disk to an Online state only when a sufficient

number of physical disks are available to support the virtual disk.
