Port Protocol Service Name
88 TCP and UDP Kerberos
123 UDP NTP
135 TCP AD ‐ RPC
138 UDP NetBIOS
139 TCP NetBIOS
161 UDP SNMP Agent
162 TCP SNMP trap
389 TCP and UDP LDAP
464 TCP and UDP Kerberos v5
543 TCP Kerberos login
544 TCP Kerberos remote shell
636 TCP LDAP over TLS/SSL
711 UDP NIS
714 TCP NIS
749 TCP and UDP Kerberos administration
1344 TCP Anti-virus ‐ ICAP
3268 TCP LDAP global catalog
3269 TCP LDAP global catalog over TLS/SSL
8004 TCP ScanEngine server WebUI (AV host)
10000 TCP NDMP
10550‐10551, 10560‐10568 TCP Replication
Other Information You May Need
WARNING: See the safety and regulatory information that shipped with your system. Warranty
information may be included within this document or as a separate document.
• The Getting Started Guide provides an overview of setting up your system and technical
specifications.
• The Owner's Manual provides information about solution features and describes how to troubleshoot
the system and install or replace system components.
• The rack documentation included with your rack solution describes how to install your system into a
rack, if required.
• The System Placemat provides information on how to set up the hardware and install the software on
your NAS solution.
• Any media that ships with your system that provides documentation and tools for configuring and
managing your system, including those pertaining to the operating system, system management
software, system updates, and system components that you purchased with your system.
• For the full name of an abbreviation or acronym used in this document, see the Glossary at dell.com/
support/manuals.
