Specifications
NOTE: Offerings may vary by region. For more information regarding
the configuration of your computer, click Start→ Help and Support
and select the option to view information about your computer.
System Information
Processor type Intel
®
i5 and i7 Dual Core
Intel Core i7 Quad Extreme
Intel Core i7 Quad
Chipset Mobile Intel 5 series chipset (QM57)
Video
Video type Discrete
Data bus
• PCI-E x16 Gen1
• PCI-E x16 Gen2
Video controller NVIDIA Quadro FX 880M
NVIDIA Quadro FX 1800M
Memory
Type DDR3, 1066 MHz / 1333 MHz
Memory module
connector
two SODIMM slots
Memory module capacity 1 GB or 4 GB
Minimum memory 2 GB
Maximum memory 8 GB
Contactless Smart Card
Supported Smart Cards
and Technologies
ISO14443A — 106 kbps, 212 kbps, 424 kbps,
and 848 kbps
ISO14443B — 106 kbps, 212 kbps, 424 kbps,
and 848 kbps
ISO15693
HID iClass
FIPS201
NXP Desfire
Battery
Type 6-cell "smart" lithium ion (60 WHr)
9-cell "smart" lithium ion (81 WHr)
9-cell "smart" lithium ion (90 WHr)
Dimensions
6-cell
Depth
206.00 mm (8.11 inches)
Height 19.80 mm (0.78 inch)
Width 47.00 mm (1.85 inches)
9-cell
Depth
208.00 mm (8.18 inches)
Height 22.30 mm (0.87 inch)
Width 69.00 mm (2.71 inches)
Weight
6-cell 329.00 g (0.72 lb)
9-cell 485.00 g (1.07 lb)
Voltage 11.10 V
