Dell™ Systems Build and Update Utility 1.0 快速参考指南 关于此说明文件 Dell Systems Build and Update Utility 概览 开始使用 Dell Systems Build and Update Utility 之前 引导菜单 服务器操作系统安装 固件更新 更新公用程序创建 硬件配置脚本工具 Content Manager 词汇表 注和注意 注 : "注"表示可以帮助更好使用计算机的重要信息。 注 意 : "注意"表示可能会对硬件造成损坏或丢失数据,并告诉您如何避免问题。 本说 明 文 件 中 的 信 息 如 有 更 改 , 恕 不另行 通 知 。 2007 Dell Inc. 版权 所 有 , 翻 印 必 究 未经 Dell Inc. 书面同意,严禁以任何形式进行复制。 本文中使用的商标:Dell、DELL 徽标、PowerEdge 和 OpenManage 是 Dell Inc.
返回目录页 关于此说明文件 Dell™ Systems Build and Update Utility 1.
返回目录页 Dell Systems Build and Update Utility 概览 Dell™ Systems Build and Update Utility 1.
Windows 和 Linux 操作系统上。 通过比较本地或自定义存储库与 Dell 联机存储库ftp.dell.
返回目录页 开始使用 Dell Systems Build and Update Utility 之前 Dell™ Systems Build and Update Utility 1.0 快 速参考 指 南 前提条件和要求 支持的操作系统 支持的系统 是否还有其他可能需要的 Dell 说明文件? 如何获得技术帮助? 本节列出了在使用 Dell™ Systems Build and Update Utility 前需要的前提条件以及使用过程中在哪里获得其他信息。 前提条件和要求 您的 Dell 系统应具有: l 最低 512 MB 内存 l CD 驱动器 l DVD 驱动器(用于固件更新) 表 3-1 列出了 Dell Systems Build and Update Utility 具体模块的前提条件和要求。 表 3-1.
是否还有其他可能需要的 Dell 说明文件? 除了本指南和 Dell Systems Build and Update Utility 联机帮助以外,可能需要参阅以下说明文件了解有关具体 Dell Systems Build and Update Utility 模块和/或 Dell OpenManage 产品的详情。 可从 Dell 支持网站 support.dell.
返回目录页 引导菜单 Dell™ Systems Build and Update Utility 1.0 快 速参考 指 南 这是 Dell™ Systems Build and Update Utility 的入口点。 要进入引导菜单: 1. 在系统驱动器中插入 Dell Systems Build and Update Utility CD 或 Dell Systems Management Tools and Documentation DVD。 2. 重新引导系统。 引导菜单屏幕将会显示。 图 4-1 显示引导菜单屏幕。 图 4-1. 引导菜单屏幕 表 4-1 列出了此屏幕中的可用选项及其描述。 表 4-1.
返回目录页 服务器操作系统安装 Dell™ Systems Build and Update Utility 1.0 快 速参考 指 南 如何访问 SOI? 我还需要知道哪些? Dell™ Systems Build and Update Utility 中 的服务器 操 作 系统安装 (SOI) 模块允许将 Dell 支持的操作系统安装在 Dell 系统。 SOI 还会将要安装的操作系统对应到您的系统并 安装必要的驱动程序。 简单的界面可以配置 Dell 支持的存储控制器。 可以使用 SOI: l 在"裸装"Dell 系统(即,系统没有安装操作系统)上部署操作系统。 l 将系统"改变用途"(即,系统已装有操作系统,用户想安装其他操作系统)。 l 抽取驱动程序并保存到系统目录。 以上所列操作均为一对一。 如何访问 SOI? 1. 从 Dell Systems Build and Update Utility 主页,单击"Server OS Installation"( 服务器 操 作 系统安装)。 2. "SOI Home"(SOI 主页)屏幕将显示。 3.
返回目录页 固件更新 Dell™ Systems Build and Update Utility 1.0 快 速参考 指 南 如何访问固件更新? 何为存储库? 我还需要知道哪些? Dell™ Systems Build and Update Utility 中的固 件 更 新模块使用户能够在预操作系统环境中更新 Dell 系统的 BIOS 和固件版本。 该模块: l 会对系统进行资源清册(BIOS、固件和驱动程序) l 允许选择自己的存储库(要了解有关存储库的更多信息,请参阅"何为存储库?") l 生成对比报告(将现有系统上每个所装组件的版本与存储库中组件的版本相比较。) l 允许升级系统组件 如何访问固件更新? 1. 从 Dell Systems Build and Update Utility 主页,单击"Firmware Update"( 固件 更 新 )。 固件更新模块中的"Repository Selection"( 存储 库 选 择)屏幕将会显示。 2. 指定更新文件所在的本地或远程存储库位置。 3.
如果使用 USB 存储 盘作为源 存储 库 l 如果使用 USB 存储盘作为源存储库,应在提示时插入 USB 存储盘。 注 : 建议不要在 USB 存储盘插入系统时引导系统到 Systems Build and Update Utility。 返回目录页
返回目录页 更新公用程序创建 Dell™ Systems Build and Update Utility 1.0 快 速参考 指 南 如何使用更新公用程序创建? 何为源存储库? 如何使用自定义存储库? 我还需要知道哪些? Dell™ Server Updates DVD 包含一个存储库,其中有 Microsoft Windows 和 Linux 操作系统的用于所支持 Dell 系统的更新软件包。Dell Systems Build and Update Utility 中的 更新 公 用程 序创建模块允许用户通过只选择所需系统和操作系统来自定义并创建更小更紧凑的更新公用程序存储库。 此自定义存储库具有 Server Update Utility 的功能。 可以使用更 新 公 用 程序创建模块在系统上进行一对一的更新。 如何使用更新公用程序创建? 1.
l 如果在同一位置创建了多个自定义存储库,更新公用程序创建模块将会创建多个文件夹,每个存储库一个。 例如,CustomRepository、CustomRepository1、 CustomRepository2 等。 如果使用 USB 存储 盘作为目标位 置 l 如果使用 USB 存储盘作为更新公用程序创建的目标位置,在得到提示后插入 USB 存储盘。 注 : 建议不要在 USB 存储盘插入系统时引导系统到 Systems Build and Update Utility。 返回目录页
返回目录页 硬件配置脚本工具 Dell™ Systems Build and Update Utility 1.0 快 速参考 指 南 如何使用硬件配置脚本工具? 如何使用命令行界面? 有关配置硬件的一些问题 如何使用 .ini 文件部署系统? 我还需要知道哪些? Dell™ Systems Build and Update Utility 中的硬 件 配 置脚本 工 具使您能够配置系统的底板管理控制器 (BMC)、Dell Remote Access Controller (DRAC)、独立磁盘冗余阵列 (RAID) 和 BIOS。 保存系统 BMC、DRAC、RAID 和 BIOS 的配置设置后,可以使用此工具生成 .ini 文件,并将这些配置设置应用到多个系统。 如何使用硬件配置脚本工具? 要访问 GUI: 从 Dell Systems Build and Update Utility 主页,单击"HW Config Scripting Tool"( 硬 件 配 置脚本 工 具 )。 1.
x9xx l l l l l l l l l l xx0x l l l l l l Raid BMC/DRAC 5/iDRAC 脚本® 常 用 BMC/DRAC 5/iDRAC 脚本® BMC (x9xx) BMC/DRAC 5/iDRAC 脚本® DRAC 5 BMC/DRAC 5/iDRAC 脚本® 警报 BMC/DRAC 5/iDRAC 脚本® 筛 选器 BMC/DRAC 5/iDRAC 脚本® 用户 BIOS 脚本® 常 用 BIOS 脚本® x9xx BIOS 脚本® 引导顺序和安全性 Raid BMC/DRAC BMC/DRAC BMC/DRAC BMC/DRAC BMC/DRAC 5/iDRAC 5/iDRAC 5/iDRAC 5/iDRAC 5/iDRAC 脚本® 常 用 脚本® iDRAC 脚本® 警报 脚本® 筛 选器 脚本® 用户 在哪里获得 有关 RAID 控制器的更多详 细? 有关读、写和高速缓存策略和支持的条带大小的详情,请参阅 《Dell OpenManage™ Deployment Toolkit 命令行界面参考指南》。 如何得知哪些 BIOS 设置选 项可用
9. 10. 浏览到 /opt/dell/toolkit/bin 文件夹。 运行 DTK 主文件: 如果系统运行 Microsoft Windows,则转至 E:\dtkrunall.bat。 如果系统运行 Linux,则使用命令: sh/mnt/usb/dtkrunall.sh 这会调用主文件并将您在步骤 1中保存的配置设置应用到系统。 一对多 情况 有关如何使用 .
返回目录页 Content Manager Dell™ Systems Build and Update Utility 1.0 快 速参考 指 南 如何使用 Content Manager? 如何使用 Content Manager 获得 Server Update Utility 应用程序? 如何使用 Content Manager 在网络共享上创建自定义存储库? 检查存储库更新对我有何帮助? 我还需要知道哪些? Content Manager 是 Dell™ Systems Build and Update Utility 中的一个工具,使您能够: l 从 Dell 联机 ftp.dell.com 下载最新的 Server Update Utility ISO 映像。 l 使用 Dell Server Updates DVD 或从 Dell 联机网站创建自定义存储库。 l 将自定义存储库保存在本地或共享位置并以后用于在预操作系统或后操作系统环境中进行系统硬件更新。 l 通过比较本地或自定义存储库与 Dell 联机存储库ftp.dell.
检查存储库更新对我有何帮助? 通过使用"Check for Repository Updates"(检查存储 库更 新 )操作,将获得有关驱动程序和固件更新的详细报告。 这将有助于评估系统需要哪些更新。 我还需要知道哪些? 如 果创建只有 Windows 软件包的自定义存储 库 l 如果创建只有 Windows 软件包的自定义存储库,将不能使用 Dell Systems Build and Update Utility 中的固 件 更 新模块通过自定义存储库来更新固件。 返回目录页
返回目录页 词汇表 Dell™ Systems Build and Update Utility 1.
