Intel Software Guard Extensions
Intel TurboBoost Enable or disable Intel TurboBoost mode of the
processor.
Default: Enabled.
HyperThread control Enable or disable HyperThreading in the processor.
Default: Enabled.
Power Management
AC Behavior Enables the system to power-on automatically,
when AC is inserted.
Auto on Time Enable to set the computer to turn on automatically
every day or on a preselected date and time. This
option can be configured only if the Auto On Time is
set to Everyday, Weekdays or Selected Days.
Default: Disabled.
USB Wake Support Enable the USB devices to wake the computer from
Standby.
Block Sleep Enable or disable the sleep state.
Peak Shift Configure the AC power usage.
Advanced Battery Charge
Configuration
Enable Advanced Battery Charge Configuration
from the beginning of the day to a specified work
period.
Primary Battery Charge
Configuration
Set the primary battery charge settings with a
preselected custom charge start and stop.
Default: Adaptive.
POST Behavior
Adapter Warnings Enable adapter warnings.
Default: Enabled.
Keypad (Embedded) Enable or disable the keypad that is embedded in
the internal keyboard.
Numlock Enable Enable or disable Numlock.
Default: Enable Numlock.
Fn Key Emulation Enable or disable the Fn key emulation.
Fn Lock Options Enable or disable the Fn lock mode.
