5711310731_00_0418 De’Longhi Appliances via Seitz, 47 31100 Treviso Italia www.delonghi.
HCX Series CONVECTOR Instructions for use This product is only suitable for well insulated spaces or occasional use
A B C D E F 1 G 2
IMPORTANT SAFEGUARDS Safety warnings Danger! Failure to observe the warning may result in life threatening injury by electric shock. Do not use the appliance near showers, bathtubs, sinks, swimming pools, etc. - Never use the appliance to dry laundry. - If the power cable is damaged, it must be replaced by the manufacturer, the manufacturer’s customer services or a qualified electrician in order to eliminate all risk.
Do not store in dusty atmospheres. - The appliance must never be hung in any way. Please note: This symbol indicates recommendations and important information for the user. - You are recommended to avoid positioning the appliance in a draught as strong air currents could reduce its efficiency. - Use the appliance on a flat stable surface. - Use the appliance in a vertical position only. - Do not use the appliance if it has been dropped or fallen over. - Do not use the appliance if it is visibly damaged.
Heating 1 The appliance operates at low power. Heating 2 The appliance operates at medium power. Heating 3 The appliance operates at high power. Heating 3 + Fan The appliance operates at the maximum power with the fan. The setting temperature range available is from 16°C to 32°C. DESCRIPTION A B C D E F Power indicator light ON/STAND-BY button +/- adjustment buttons MODE button (selects the operating mode) “ECO plus” button Timer button General instructions Remove the heater from the packaging.
Changing of the temperature scale The display can show the temperature in both °F (Fahrenheit) and °C (Celsius). To select the desired temperature scale, when the unit is in standby position, press and hold the "+" key for at least 10 seconds, then release. The change of scale will be indicated by two short beeps. The symbol is displayed flashing together with the hours left before the appliance comes on. Change the hours using the + and - buttons, then wait a few seconds for the program to be stored.
TROUBLESHOOTING PROBLEM The appliance doesn't work CAUSE SOLUTION Be sure it is plugged in and that the electrical Plug into the power outlet outlet is working The temperature may be set too low Set the temperature higher The Key lock may be activated See the section "Key lock" The timer is not correctly programmed Program the timer correctly The appliance doesn't work The air intake or outlet grille is obstructed (the display could blink and you could hear an intermittent "beep") Remove the obstr
