13.1 _DMC_01_ipo_set_svon
 FORMAT
I16 PASCAL _DMC_01_ipo_set_svon (U16 CardNo, U16 NodeID, U16 SlotID, U16 ON_OFF)
 Purpose
Sets Servo ON/OFF under PDO protocol mode.
 Parameters
Name Data Type Unit Description
CardNo U16 Number Unit CardNo is between 0~15
NodeID U16 Number Unit Node ID
SlotID U16 Number Unit Slot ID
ON_OFF U16 Selection
0: Servo OFF
1: Servo ON
 Example
U16 CardNo=0;
U16 NodeID =1;
U16 SlotID =0;
U16 ON_OFF=1;
I16 status= _DMC_01_ipo_set_svon (CardNo, NodeID, SlotID, ON_OFF);
