37.17 _misc_slave_user_data_buffer_write
 FORMAT
I16 PASCAL _misc_slave_user_data_buffer_write (U16 CardNo, U16 NodeID, U16 SlotID
U16 Address, U32 Data)
 Purpose
Writes data to buffer.
 Parameters
Name Data Type Unit Description
CardNo U16 Number Unit CardNo is between 0~15
NodeID U16 Selection Node ID
SlotID U16 Number Unit Slot ID
Address U16 Number Position to write to
Data U32 Number Data to write
 Example
U16 CardNo=0;
U16 NodeID=1;
U16 SlotID=0;
U16 Address;
U32 Data;
I16 status = _ misc_slave_user_data_buffer_write (CardNo, NodeID, SlotID, Address, Data);
