Chapter 3 Element Function|ScrEdit Software User Manual
3-18 Revision Apr. 30th, 2007, 2007PDD23000002
Property Description of System Function Buttons
After Execute Macro If this option is set, when the user presses the button, the system will perform the
operation of this button first and then execute the command of this macro. But, if
the state of the button is not triggered by pressing the button (via macro or external
signal), the command of this macro will not be executed.
