Chapter 5 Control Block and Status Block|ScrEdit Software User Manual
Revision Apr. 30th, 2007, 2007PDD23000002 5-11
Curve Sampling Status Flag
When sampling general trend graph or X-Y chart, the curve sampling status flag will be set to be ON
(Bit 0 ~ Bit 3 is set to ON). After sampling operation is completed, the curve sampling status flag will be
OFF.
Curve Clear Status Flag
When clearing general trend graph or X-Y chart, the curve clear status flag will be set to be ON (Bit 8 ~
Bit 11 is set to ON). After clear operation is completed, the curve clear status flag will be OFF.
Status Register for Sampling History Buffer (HSSR)
Bit Number
Function
0 Sampling Status of History Buffer 1
1 Sampling Status of History Buffer 2
2 Sampling Status of History Buffer 3
3 Sampling Status of History Buffer 4
4 Sampling Status of History Buffer 5
5 Sampling Status of History Buffer 6
6 Sampling Status of History Buffer 7
7 Sampling Status of History Buffer 8
8 Sampling Status of History Buffer 9
9 Sampling Status of History Buffer 10
10 Sampling Status of History Buffer 11
11 Sampling Status of History Buffer 12
12-15 Reserved
Sampling History Buffer Flag
When sampling history buffer, the sampling history buffer flag will be set to be ON (Bit 0 ~ Bit 11 is set
to ON). After sampling operation is completed, the sampling history buffer flag will be OFF.
Status Register for Clearing History Buffer (HCSR)
Bit Number
Function
0 Clear Status of History Buffer 1
1 Clear Status of History Buffer 2
2 Clear Status of History Buffer 3
3 Clear Status of History Buffer 4
4 Clear Status of History Buffer 5
5 Clear Status of History Buffer 6
6 Clear Status of History Buffer 7
7 Clear Status of History Buffer 8
8 Clear Status of History Buffer 9
