Appendix A Specifications
Voltage Class 115V Class
Model Number VFD-_ _ _S 002 004 007
Max. Applicable Motor Output (kW) 0.2 0.4 0.75
Max. Applicable Motor Output (HP) 0.25 0.5 1.0
Rated Output Capacity (KVA) 0.6 1.0 1.6
Rated Output Current (A) 1.6 2.5 4.2
Maximum Output Voltage (V) 3-phase Proportional to Twice the Input Voltage
Output Frequency (Hz) 1.0~400 Hz
Output Rating
Carrier Frequency (kHz) 3-10
Single phase
Rated Input Current (A)
6 9 18
Rated Voltage/Frequency Single phase 100-120 V, 50/60Hz
Voltage Tolerance +-10%(90-132V)
Input Rating
Freqency Tolerance +-5%(47~63Hz)
Cooling Method Natural
Weight (kg) 1.3 1.5 2.0
Voltage Class 230V Class
Model Number VFD-_ _ _S 002 004 007 015 022
Max. Applicable Motor Output (kW) 0.2 0.4 0.75 1.5 2.2
Max. Applicable Motor Output (HP) 0.25 0.5 1.0 2.0 3.0
Rated Output Capacity (KVA) 0.6 1.0 1.6 2.9 4.4/4.2
Rated Output Current (A) 1.6 2.5 4.2 7.5 11.0
Maximum Output Voltage (V) 3-phase Proportional to Input Voltage
Output Frequency (Hz) 1.0~400 Hz
Output Rating
Carrier Frequency (kHz) 3-10
Single/3-phase
Rated Input Current (A)
4.9/1.9 6.5/2.7 9.7/5.1 15.7/9.0 24/15
Input Current for 1-phase model
drive to be used as 3-phase
model drive (A)
1.6 3.0 5.1 8.4 -
Rated Voltage/Frequency Single/3-phase 200-240 V, 50/60Hz
Voltage Tolerance +-10%(180~264 V)
Input Rating
Freqency Tolerance +-5%(4~63 Hz)
Cooling Method Natural Fan Cooled
Weight (kg) 1.3 1.5 1.5 2.2 2.5
