COMPLIES WITH:

•

ASME A112.18.1 / CSA B125.1

•

ASME A112.18.2 / CSA B125.2

Indicates compliance to

ICC/ANSI A117.1

LAVATORY FAUCETS

■ Classic Series

■ Two Handle Deck Mount

Submitted Model No.:

Specific Features:

STANDARD SPECIFICATIONS:

• Maximum 1.2 gpm @ 60 psi, 4.5 L/min @ 414 kPa

• Solid brass fabricated body

• Two or three hole mount

• Hot/cold indicators

• 1/4 turn handle stops

• Control mechanism is a rotating cylinder with

stainless steel plate and 90° rotation, with

replaceable non-metallic seats operating in

stainless steel lined sockets

• Models with suffix "MPU" have metal drain

with pop-up type fitting with plated flange

and stopper

• 2510LF model has spout lift rod hole but comes

without lift rod, finial, and pop-up

2500LF▲

2510LF▲

4" Centers

(102 mm)

1/2"-14

NPSM

(51 mm)

2 11/32"

(59 mm)

(51 mm)

1 11/16"

(43 mm)

Max. Deck

Thickness

5 1/4"

(133 mm)

Delta reserves the right (1) to make changes in specifications and materials, and (2) to change or discontinue

models, both without notice or obligation. Dimensions are for reference only. See current full-line price book or

www.deltafaucet.com for finish options and product availability.

2 1/8"

(54 mm)

Dia.

1 1/4"

(32 mm)

Dia.

3 3/8"

(86 mm)

4 5/8

(118 mm)

1 3/8"

(35 mm)

Dia.

1 5/8"

(42 mm)

2 3/8"

(61 mm)

3 1/4"

(83 mm)

(178 mm)

WARRANTY

•

Lifetime limited warranty on parts (other than

electronic parts and batteries) and finishes:

or, for commercial users, for 5 years from the

date of purchase.

•

5 year limited warranty on electronic parts

(other than batteries); or, for commercial

users, for 1 year from the date of purchase.

No warranty is provided on batteries.

2520LF▲

2520LF-MPU

DSP-L-2500LF Rev. F

2 1/8"

(54 mm)

Dia.

1 1/4"

(32 mm)

Dia.

4 7/8"

(124 mm)

4 1/32

(102 mm)

1 3/8"

(35 mm)

Dia.

1 5/8"

(42 mm)

2 1/4"

(57 mm)

1 1/2"

(38 mm)

Metal Pop-Up Plastic Pop-Up

▲ Designate proper finish suffix

•

Verified compliant with .25% weighted

average Pb content regulations.

• EPA WaterSense

Delta Faucet Company

55 E. 111th Street, Indianapolis, IN 46280

350 South Edgeware Road, St. Thomas, ON N5P 4L1
