Technical Specifications

ManualsBrandsDelta ManualsBathAubrey™ Two-Handle 4" Centerset Bathroom Faucet in Chrome

DSP-L-25704LF Rev. D

▲ Designate proper finish suffix

COMPLIES WITH:

•

ASME A112.18.1 / CSA B125.1

•

ASME A112.18.2 / CSA B125.2

Indicates compliance to

ICC/ANSI A117.1 - Valve control only

• EPA

WaterSense

•

Verified compliant with 0.25% weighted

average Pb content regulations.

Delta Faucet Company

55 E. 111th Street, Indianapolis, IN 46280

350 South Edgeware Road, St. Thomas, ON N5P 4L1

WARRANTY

•

Parts and Finish - Lifetime limited warranty; or for

commercial purchasers, 10 years for multi-family

residential (apartments and condominiums) and

5 years for all other commercial uses, in each case

from the date of purchase.

•

Electronic Parts and Batteries (if applicable) - 5

years from the date of purchase; or for commercial

purchasers, 1 year from the date of purchase. No

warranty is provided on batteries.

STANDARD SPECIFICATIONS:

• Max. flow rate 1.5 gpm @ 60 PSI, 5.7 L/min @ 414 kPa

• Two handle lavatory faucets for exposed mounting

on 3 hole sinks with 4" centers

• Hot and cold stems are interchangeable

• 1/4 turn handle stops

• 1/2"-14 NPSM threaded male inlet shanks

• Control mechanism is a rotating cylinder type with

stainless steel plate and 90° rotation, with

replaceable non-metallic seats

BATHROOM FAUCET

■ Aubrey™ Bath Suite

■ Two Handle Deck Mount

Submitted Model No.:

Specific Features:

25704LF ▲

2 1/8"

(54 mm)

Dia.

3 1/2"

(89 mm)

4 7/8"

(124 mm)

1 1/4"

(32 mm)

Dia.

1 5/8" (42 mm)

2 3/8" (61 mm)

(229 mm)

(101 mm)

(102 mm)

Centers

1 1/4"

(30 mm)

Max. Deck

Thickness

6 3/8"

(162 mm)

1/2"-14 NPSM

4 3/4"

(119 mm)

3 3/4"

(98 mm)

5 1/4"

(133 mm)

2 3/8"

(60 mm)

2 3/16"

(55mm)

Min. 2 1/2" (64 mm)

Clearance to Back Splash

Recommended

3 X 1 1/8"~1 1/2"

(29~38 mm)

Hole Size

Delta reserves the right (1) to make changes in specifications and materials, and (2) to change or discontinue

models, both without notice or obligation. Dimensions are for reference only. See current full-line price book or

www.deltafaucet.com for finish options and product availability.
